Keysight P9372B Vector Network Analyzer
Request a quote
Keysight P9372B is a compact 2-port vector network analyzer with Thunderbolt 3 interface, operating 9 kHz to 9 GHz with 115 dB dynamic range and 0.0015 dB rms trace noise.
Product details
| Model | P9372B |
| Manufacturer | Keysight |
| Category | Vector Network Analyzers |
| Availability | Made to order |
Description
Overview
The Keysight P9372B is a compact 2-port vector network analyzer from the Streamline Series, designed for portable network analysis without compromising performance. Operating from 9 kHz to 9 GHz with a Thunderbolt 3 interface, it can be controlled by an external computer with powerful data processing capabilities. The P9372B features the same measurement science as Keysight's benchtop PNA and ENA analyzers.
Key Features
- Frequency range: 9 kHz to 9 GHz
- 2 test ports with 3.5 mm (female) connectors
- Thunderbolt 3 interface for high-speed data transfer
- Dynamic range: 115 dB at 10 Hz IFBW
- Trace noise: 0.0015 dB rms at 10 kHz IFBW
- Output power: 8 dBm
- Measurement cycle time: less than 15 msec for 2-port measurements (201 points)
- Temperature stability: 0.005 dB/°C
- Supports Keysight electronic calibration (ECal) modules
- Compact weight: 1.88 kg
Applications
- General-purpose passive component characterization
- Time domain analysis with enhanced TDR
- Automatic fixture removal and de-embedding
- Portable field testing and multi-location deployment
- R&D and manufacturing test environments
Specifications
| High Frequency (range) | 1GHz <= 10GHz |
| Low Frequency (range) | 1kHz <= 100kHz |
