Keysight P9371B Vector Network Analyzer
Request a quote
Keysight P9371B — portable 2-port vector network analyzer up to 6.5 GHz with 115 dB dynamic range and Thunderbolt 3 interface.
Product details
| Model | P9371B |
| Manufacturer | Keysight |
| Category | Vector Network Analyzers |
| Availability | Made to order |
Description
Overview
The Keysight P9371B is a compact, portable vector network analyzer from the P93xxB Streamline Series. Controlled via an external computer with Thunderbolt 3 interface, it offers excellent performance for general-purpose network analysis and passive component characterization. The P9371B operates from 9 kHz to 6.5 GHz with 2 ports using 3.5 mm (female) connectors.
Key Features
- Compact form factor for easy sharing between test locations
- Frequency range: 9 kHz to 6.5 GHz (2-port)
- Dynamic range: 115 dB at 10 Hz IFBW
- Output power: 8 dBm
- Trace noise: 0.0015 dB rms at 10 kHz IFBW
- Measurement cycle time: less than 15 msec for 2-port, 201 points (typical)
- Temperature stability: less than 0.005 dB/°C (typical)
- High-speed Thunderbolt 3 interface
- Consistent with Keysight VNA measurement science and GUI
- Support for Keysight mechanical calibration kits and Electronic calibration (ECal) modules
Applications
- Passive component characterization (filters, couplers, antennas)
- Time domain analysis with TDR (Time Domain Reflectometry)
- Fixture characterization and automatic fixture removal
- General-purpose RF/microwave network analysis
Specifications
| High Frequency (range) | 1GHz <= 10GHz |
| Low Frequency (range) | 1kHz <= 100kHz |
