Keysight P9370B Vector Network Analyzer
Request a quote
Keysight P9370B is a compact Thunderbolt 3 vector network analyzer with 2 ports, covering 9 kHz to 4.5 GHz, featuring 115 dB dynamic range and ultra-low noise.
Product details
| Model | P9370B |
| Manufacturer | Keysight |
| Category | Vector Network Analyzers |
| Availability | Made to order |
Description
Overview
The Keysight P9370B is an updated compact vector network analyzer featuring a high-speed Thunderbolt 3 interface. This affordable VNA dramatically reduces test setup size while delivering excellent performance in general-purpose network analysis for passive components. The PC-controlled design offers powerful data processing capabilities and an intuitive GUI consistent with other Keysight VNAs.
Key Features
- Most compact VNA design for easy sharing between test locations
- High-speed Thunderbolt 3 interface for improved connectivity
- Wide dynamic range exceeding 115 dB at 10 Hz IFBW
- Ultra-low trace noise of 0.0015 dBrms at 10 kHz IFBW
- Fast cycle time: less than 15 msec for 2-port measurements at 201 points
- Excellent temperature stability of 0.005 dB/degree C
- Supports all Keysight mechanical calibration kits and Electronic Calibration (ECal) modules
- Extended frequency coverage options up to 44 GHz for 2-port models
Applications
- Passive component characterization with TDR and fixture removal
- RF and microwave network analysis
- Field and portable testing applications
- Benchtop performance in portable form factor
Specifications
| High Frequency (range) | 1GHz <= 10GHz |
| Low Frequency (range) | 1kHz <= 100kHz |
