Keysight P5026B/402 Vector Network Analyzer
Keysight P5026B/402 is a 4-port vector network analyzer with 32 GHz capability, Thunderbolt 3 interface, built-in second source for IMD testing, and portable design.
Product details
| Model | P5026B/402 |
| Manufacturer | Keysight |
| Category | Vector Network Analyzers |
| Availability | Made to order |
Description
Overview
The Keysight P5026B/402 is a 4-port vector network analyzer with 32 GHz capability and built-in second source, part of the Streamline Series portable VNA family. Designed for high-speed RF measurements via Thunderbolt 3 connectivity, this lightweight instrument delivers fast, reliable, and repeatable results across its full frequency range. The integrated second source enables intermodulation distortion measurements without external equipment, making it ideal for advanced RF characterization in portable and multi-location test environments.
Key Features
- 4-port configuration with internal second source for IMD measurements
- Frequency range from 9 kHz to 32 GHz
- Thunderbolt 3 interface (USB Type-C) for direct, high-speed PC control
- Lightweight, hand-portable design for flexible deployment
- Best-in-class dynamic range and measurement speed
- Low trace noise and excellent temperature stability
- Electronic Calibration (ECal) module support
- Wide range of software applications for advanced measurements
Applications
- Intermodulation distortion (IMD) testing with integrated dual-source configuration
- S-parameter measurements and device characterization
- Time domain analysis and fixture removal
- High-power RF device testing and evaluation
- Portable RF measurements in field, lab, and classified environments
Specifications
| Number of Ports | 4 |
| Maximum Frequency | 32 GHz |
| Minimum Frequency | 9 kHz |
| Type | PC Based |
| Dynamic Range | 137 dB |
| Series | P50xxB Streamline Series |
| Input Impedance | 50 Ω |
| Interface | Thunderbolt 3 |
