Keysight P5025B/400 Vector Network Analyzer

Overview

The Keysight P5025B/400 is a portable, four-port vector network analyzer in the Streamline Series offering measurements from 9 kHz to 26.5 GHz. The P5025B/400 delivers high-performance RF characterization in a compact form factor with lightweight design suitable for laboratory and field applications. The instrument connects to your host PC via high-speed Thunderbolt 3 (USB Type-C) interface for streamlined measurements and rapid data transfer.

Key Features

• Four-port configuration, 9 kHz to 26.5 GHz frequency range
• 140 dB dynamic range at 3 GHz, 132 dB at 20 GHz
• High-speed Thunderbolt 3 (USB Type-C) connectivity for rapid data transfer
• Portable, lightweight design ideal for laboratory and field environments
• Wide range of software applications for advanced RF measurements
• Electronic Calibration (ECal) module support for fast, accurate calibration
• Measurement speed of 1.3 ms at 1 MHz IFBW (B-model)
• Optional software for TDR analysis, noise figure, and advanced applications

Applications

• Passive component testing and characterization
• Amplifier S-parameter and gain compression measurements
• Frequency converter and mixer characterization
• Time domain analysis with TDR
• Active device measurements with optional software
• Cascaded VNA configurations for extended capability
