Keysight P5023B/600 Vector Network Analyzer
Request a quote
Keysight P5023B/600 is a portable 6-port vector network analyzer with 14 GHz coverage and 140 dB dynamic range for multiport RF characterization.
Product details
| Model | P5023B/600 |
| Manufacturer | Keysight |
| Category | Vector Network Analyzers |
| Availability | Made to order |
Description
Overview
The Keysight P5023B/600 is a portable six-port vector network analyzer delivering high-performance RF measurements up to 14 GHz. With six test ports, it enables simultaneous characterization of complex RF networks and multiport devices. Its lightweight, compact form factor maintains portability while providing the measurement capability of laboratory instruments. Thunderbolt 3 connectivity ensures fast data acquisition and analysis.
Key Features
- Six-port configuration for multi-device and network characterization
- Frequency range: 9 kHz to 14 GHz with 140 dB dynamic range
- Portable and lightweight design for field and lab deployment
- Fast Thunderbolt 3 interface with USB Type-C connectivity
- Simultaneous multi-parameter measurements with full N-port calibration
- Keysight Electronic Calibration (ECal) modules for quick setup
Applications
- Multiport RF network characterization and analysis
- Passive and active device testing
- Complex transmission line and interconnect measurements
- Portable validation of RF systems with multiple interfaces
Specifications
| Number of Ports | 6 |
| Maximum Frequency | 14 GHz |
| Minimum Frequency | 9 kHz |
| Type | PC Based |
| Dynamic Range | 142 dB |
| Series | P50xxB Streamline Series |
| Input Impedance | 50 Ω |
| Interface | Thunderbolt 3 |
