Keysight P5023B/402 Vector Network Analyzer
Request a quote
Keysight P5023B/402 is a portable 4-port vector network analyzer with built-in dual source for IMD testing and 14 GHz frequency coverage.
Product details
| Model | P5023B/402 |
| Manufacturer | Keysight |
| Category | Vector Network Analyzers |
| Availability | Made to order |
Description
Overview
The Keysight P5023B/402 is a portable four-port vector network analyzer with an integrated second source, designed for advanced RF measurements up to 14 GHz. The built-in dual-source capability enables intermodulation distortion (IMD) testing without external equipment, while maintaining the portability and ease-of-use of the Streamline Series. Thunderbolt 3 connectivity and compact dimensions make it ideal for field-based RF characterization.
Key Features
- Four-port configuration with built-in second source for dual-tone measurements
- Frequency range: 9 kHz to 14 GHz with 140 dB dynamic range
- Intermodulation distortion (IMD) capability without additional external equipment
- Portable design optimized for field testing and space-constrained labs
- Fast Thunderbolt 3 interface with USB Type-C connectivity
- Keysight Electronic Calibration (ECal) modules for streamlined calibration
Applications
- Intermodulation distortion (IMD) characterization of RF devices
- Dual-tone S-parameter measurements
- High-power device testing at multiple frequency tones
- Portable RF system validation and field deployment
Specifications
| Number of Ports | 4 |
| Maximum Frequency | 14 GHz |
| Minimum Frequency | 9 kHz |
| Type | PC Based |
| Dynamic Range | 142 dB |
| Series | P50xxB Streamline Series |
| Input Impedance | 50 Ω |
| Interface | Thunderbolt 3 |
