Keysight P5023B/400 Vector Network Analyzer
Request a quote
Keysight P5023B/400 is a portable 4-port vector network analyzer with 14 GHz coverage, 140 dB dynamic range, and Thunderbolt 3 interface for RF component characterization.
Product details
| Model | P5023B/400 |
| Manufacturer | Keysight |
| Category | Vector Network Analyzers |
| Availability | Made to order |
Description
Overview
The Keysight P5023B/400 is a portable four-port vector network analyzer delivering RF measurements up to 14 GHz. Its compact, lightweight design enables deployment in space-constrained environments while maintaining the measurement accuracy and dynamic range of larger benchtop systems. Fast Thunderbolt 3 connectivity and comprehensive software options make it an ideal solution for RF component characterization.
Key Features
- Four-port configuration with 9 kHz to 14 GHz frequency coverage
- Portable design — easily carried for field testing and mobile applications
- 140 dB dynamic range for sensitive, low-noise measurements
- Fast Thunderbolt 3 interface for rapid data transfer
- Quick calibration with Keysight Electronic Calibration (ECal) modules
- Cascadable design to extend port configurations with multiple units
Applications
- RF component characterization and S-parameter measurements
- Field testing of passive and active RF devices
- Amplifier and frequency converter evaluation
- Time-domain analysis with optional TDR software
Specifications
| Number of Ports | 4 |
| Maximum Frequency | 14 GHz |
| Minimum Frequency | 9 kHz |
| Type | PC Based |
| Dynamic Range | 142 dB |
| Series | P50xxB Streamline Series |
| Input Impedance | 50 Ω |
| Interface | Thunderbolt 3 |
