Keysight P5022B/402 Vector Network Analyzer

Overview

The Keysight P5022B/402 is a portable 4-port vector network analyzer with a built-in second source, delivering high-performance RF characterization in a compact form factor. Operating from 9 kHz to 9 GHz, it connects via Thunderbolt 3 to a host PC, enabling fast and repeatable measurements with a hand-portable design ideal for space-constrained and mobile applications.

The integrated second source enables intermodulation distortion (IMD) measurements where each source generates a distinct tone, allowing simultaneous multi-tone testing without external signal combiners.

Key Features

• 4-port configuration with 9 kHz to 9 GHz frequency range
• Built-in second source for intermodulation distortion (IMD) measurements
• Fast Thunderbolt 3 interface (USB Type-C) for connectivity to host PC
• Hand-portable design enabling flexible deployment in various measurement scenarios
• Wide dynamic range (140 dB @ 3 GHz) with low trace noise for accurate measurements
• Quick calibration with Keysight Electronic Calibration (ECal) modules
• Software applications for TDR, noise figure measurement, spectrum analysis, and advanced IMD characterization
• Cascading capability to extend test port count for complex multi-instrument configurations
• Direct Receiver Access (DRA) configurations for advanced measurement setups
• No on-board data storage for compatibility with classified environments

Applications

• Intermodulation distortion (IMD) measurements of amplifiers and RF components
• Two-tone and multi-tone testing without external signal combiners
• S-parameter measurements of high-power RF devices
• Passive component characterization and testing
• Amplifier and frequency converter measurements
• Time domain analysis and automatic fixture removal
• Spectrum analysis and noise figure measurement
