Keysight P5021B/402 Vector Network Analyzer with Second Source

Overview

The Keysight P5021B/402 is a 4-port vector network analyzer with integrated second source, designed for portable RF measurements from 9 kHz to 6.5 GHz. Part of the Streamline Series, it connects via Thunderbolt 3 to a host PC, enabling fast network analysis with a compact form factor. The second source option (402) allows each built-in source to generate distinct tones, making it ideal for intermodulation distortion (IMD) measurements and advanced characterization requiring multiple stimulus signals.

Key Features

• 9 kHz to 6.5 GHz frequency range with 4-port configuration and second source
• Dual independent sources for IMD and multi-tone measurements
• Thunderbolt 3 (USB Type-C) connectivity for fast data transfer
• 140 dB dynamic range at 3/20 GHz (10 Hz IFBW)
• −130/−122 dBm noise floor at 3/20 GHz (10 Hz IFBW)
• Portable design with one-hand operation capability
• Compatible with Keysight Electronic Calibration (ECal) modules
• No internal data storage, suitable for classified environments

Applications

• Intermodulation distortion (IMD) measurements with S97087B software
• Multi-tone frequency characterization
• Passive component and amplifier testing
• S-parameter measurements of high-power devices
• Frequency converter and mixer characterization
• Time domain analysis and TDR measurements
• Active component measurements with dual-stimulus capability
