Keysight P5021B/400 Vector Network Analyzer
Request a quote
P5021B/400 is a 4-port vector network analyzer with 9 kHz to 6.5 GHz coverage, 140 dB dynamic range, and Thunderbolt 3 connectivity for portable RF measurements.
Product details
| Model | P5021B/400 |
| Manufacturer | Keysight |
| Category | Vector Network Analyzers |
| Availability | Made to order |
Description
Overview
The Keysight P5021B/400 is a 4-port vector network analyzer designed for portable RF measurements from 9 kHz to 6.5 GHz. Part of the Streamline Series, it connects via Thunderbolt 3 to a host PC, enabling fast network analysis with a compact form factor and lightweight design suitable for one-hand operation. The instrument delivers excellent performance with 140 dB dynamic range, low trace noise, and temperature stability for laboratory and field applications.
Key Features
- 9 kHz to 6.5 GHz frequency range with 4-port configuration
- Thunderbolt 3 (USB Type-C) connectivity for fast data transfer
- 140 dB dynamic range at 3/20 GHz (10 Hz IFBW)
- −130/−122 dBm noise floor at 3/20 GHz (10 Hz IFBW)
- Portable design with one-hand operation capability
- Compatible with Keysight Electronic Calibration (ECal) modules
- Multiple software applications for RF characterization
- No internal data storage, suitable for classified environments
Applications
- S-parameter measurements of high-power devices
- Passive component and amplifier characterization
- Frequency converter testing and analysis
- Time domain analysis and TDR measurements
- Intermodulation distortion (IMD) measurements
- Noise figure characterization
- Active component and spectrum analysis
Specifications
| Number of Ports | 4 |
| Maximum Frequency | 6.5 GHz |
| Minimum Frequency | 9 kHz |
| Type | PC Based |
| Dynamic Range | 148 dB |
| Series | P50xxB Streamline Series |
| Input Impedance | 50 Ω |
| Interface | Thunderbolt 3 |
