Keysight P5020B/402 Vector Network Analyzer
Request a quote
Keysight P5020B/402 — 4-port vector network analyzer with built-in second source, frequency range 9 kHz to 4.5 GHz, ideal for intermodulation distortion testing.
Product details
| Model | P5020B/402 |
| Manufacturer | Keysight |
| Category | Vector Network Analyzers |
| Availability | Made to order |
Description
Overview
The Keysight P5020B/402 is a compact, portable 4-port vector network analyzer with integrated second source, specifically designed for intermodulation distortion (IMD) measurements. Operating from 9 kHz to 4.5 GHz via Thunderbolt 3 connectivity, this Streamline Series VNA delivers accurate two-tone testing capabilities in a lightweight, space-efficient package suitable for advanced RF characterization and field measurements.
Key Features
- 4-port configuration with built-in second source (option 402) for two-tone IMD testing
- Frequency range from 9 kHz to 4.5 GHz
- Fast Thunderbolt 3 interface (USB Type-C connectors)
- Compact and lightweight design — portable with one-hand carry
- Each internal source generates distinct tones for precise IMD measurements
- Advanced RF characterization software applications included
- Electronic Calibration (ECal) module support
- Cascadable design for extended test configurations
- No on-board data storage — suitable for classified environments
Applications
- Intermodulation distortion (IMD) measurements with software application S97087B
- Two-tone RF testing and device characterization
- Passive and active component measurements
- Portable field measurements and multi-location testing
- Power leveling and frequency conversion analysis
Specifications
| Number of Ports | 4 |
| Maximum Frequency | 4.5 GHz |
| Minimum Frequency | 9 kHz |
| Type | PC Based |
| Dynamic Range | 149 dB |
| Series | P50xxB Streamline Series |
| Input Impedance | 50 Ω |
| Interface | Thunderbolt 3 |
