Keysight P5020B/400 Vector Network Analyzer
Request a quote
Keysight P5020B/400 — 4-port vector network analyzer with Thunderbolt 3 interface, frequency range from 9 kHz to 4.5 GHz, designed for portable RF measurements.
Product details
| Model | P5020B/400 |
| Manufacturer | Keysight |
| Category | Vector Network Analyzers |
| Availability | Made to order |
Description
Overview
The Keysight P5020B/400 is a compact, portable 4-port vector network analyzer offering high-end RF measurement capabilities from 9 kHz to 4.5 GHz. Part of the Streamline Series, this faceless VNA features Thunderbolt 3 connectivity and delivers fast, reliable, and repeatable measurements in a lightweight package ideal for space-constrained environments and multi-location testing.
Key Features
- 4-port configuration with frequency range from 9 kHz to 4.5 GHz
- Fast Thunderbolt 3 interface (USB Type-C connectors) for quick connectivity
- Compact and lightweight — portable with one-hand carry capability
- Advanced RF characterization software applications included
- Electronic Calibration (ECal) module support for quick calibration
- Cascadable design — extend test capabilities by connecting multiple units
- No on-board data storage — suitable for classified environments
- Consistent measurement GUI and SCPI commands across Keysight VNA platforms
Applications
- Passive component characterization (filters, couplers, splitters)
- Amplifier and frequency converter testing
- RF device measurements in space-constrained labs
- Portable field measurements and multi-location testing
- Time-domain analysis and fixture removal with optional software
Specifications
| Number of Ports | 4 |
| Maximum Frequency | 4.5 GHz |
| Minimum Frequency | 9 kHz |
| Type | PC Based |
| Dynamic Range | 149 dB |
| Series | P50xxB Streamline Series |
| Input Impedance | 50 Ω |
| Interface | Thunderbolt 3 |
