Keysight P5008B/200 Vector Network Analyzer
Request a quote
Keysight P5008B/200 — compact 2-port vector network analyzer with 100 kHz to 53 GHz coverage, Thunderbolt 3 interface, and portable design.
Product details
| Model | P5008B/200 |
| Manufacturer | Keysight |
| Category | Vector Network Analyzers |
| Availability | Made to order |
Description
Overview
The Keysight P5008B/200 is a compact, portable 2-port vector network analyzer offering high-frequency measurement capabilities up to 53 GHz. Designed for space-constrained laboratory and field environments, this faceless VNA connects via Thunderbolt 3 interface to a host PC, delivering fast and reliable measurements with minimal footprint and weight, making it ideal for portable applications and measurement teams.
Key Features
- 2-port configuration with frequency range from 100 kHz to 53 GHz
- Fast Thunderbolt 3 interface (USB Type-C connectors) for quick data transfer
- Compact and lightweight design — portable with one-hand carry
- Advanced RF characterization software applications included
- Electronic Calibration (ECal) module support for quick calibration
- Cascadable design — extend test ports by connecting two units
- No on-board data storage — suitable for classified environments
- Consistent measurement GUI and SCPI commands across Keysight VNA platforms
Applications
- Passive component characterization (filters, couplers, connectors)
- Amplifier and frequency converter testing
- RF device measurements in space-constrained labs
- Portable field measurements and multi-location testing
- Fixture removal and time-domain analysis with optional software
Specifications
| Number of Ports | 2 |
| Maximum Frequency | 53 GHz |
| Minimum Frequency | 100 kHz |
| Type | PC Based |
| Dynamic Range | 101 dB |
| Series | P50xxB Streamline Series |
| Input Impedance | 50 Ω |
| Interface | Thunderbolt 3 |
