Keysight P5007B/200 Vector Network Analyzer

Overview

The Keysight P5007B/200 is a compact, 2-port vector network analyzer from the Streamline Series, designed for high-speed RF measurements via Thunderbolt 3 connectivity. Spanning 100 kHz to 44 GHz with 2.4 mm (f) connectors, it delivers robust performance in a lightweight, portable package suitable for laboratory, manufacturing, and field applications. Its small footprint can be carried with one hand, making it ideal for space-constrained test environments and portable measurement setups.

The P5007B/200 inherits the measurement science and performance standards of Keysight's trusted high-performance VNAs. It offers fast, reliable, and repeatable results with advanced RF characterization capabilities, allowing you to test passive components, amplifiers, and frequency converters with confidence.

Key Features

• Frequency range: 100 kHz to 44 GHz, 2-port configuration
• Fast Thunderbolt 3 interface (USB Type-C) for high-speed data transfer
• Compact, lightweight, hand-portable form factor
• 2.4 mm (f) test port connectors
• Portable VNA sharing across teams and locations
• Cascade capability: extend ports by connecting two VNAs
• Same GUI, SCPI commands, and measurement science as Keysight high-performance VNAs
• Keysight Electronic Calibration (ECal) module support for quick calibration
• Rich suite of software applications including TDR and fixture removal
• No onboard data storage, suitable for classified environments
• Hardware upgradeable with performance-enabling software options

Applications

• Passive component characterization and testing
• Amplifier and mixer performance evaluation
• Frequency converter measurement
• Manufacturing and field RF testing
• Portable laboratory RF measurements
• Classified environment measurements (no internal storage)

Included Accessories

• Thunderbolt 3 cable assembly (800 mm)
• External AC-DC power supply
• Power cord
