Keysight P5003B/200 Vector Network Analyzer

Overview

The Keysight P5003B/200 is a compact, portable, two-port vector network analyzer designed for high-speed RF measurements. Part of the Streamline Series, it operates from 9 kHz to 14 GHz and connects via Thunderbolt 3 to a host PC, dramatically reducing test setup size while maintaining performance. This lightweight instrument is ideal for space-constrained environments, portable applications, and shared laboratory setups requiring flexible network analysis capabilities.

Key Features

• 2-port, 9 kHz to 14 GHz frequency range
• Fast Thunderbolt 3 interface (USB Type-C) for high-speed connectivity
• Compact, faceless design with lightweight single-hand portability
• Wide range of measurement applications for diverse RF characterization
• Support for cascading multiple VNAs to extend test port count
• Identical GUI and SCPI commands as Keysight high-performance VNAs
• Fast calibration with Keysight Electronic Calibration (ECal) modules
• No on-board data storage for classified environments
• Software upgradeable hardware capabilities

Applications

• Testing passive components (filters, couplers, antennas)
• Amplifier and mixer characterization
• Frequency converter measurements
• Portable field testing and measurements
• Multi-site and distributed laboratory measurements
• RF component quality assurance and validation
