Keysight P5002B/200 Vector Network Analyzer
Request a quote
Keysight P5002B/200 is a portable 2-port VNA with Thunderbolt 3, delivering network analysis up to 9 GHz in a compact design.
Product details
| Model | P5002B/200 |
| Manufacturer | Keysight |
| Category | Vector Network Analyzers |
| Availability | Made to order |
Description
Overview
The Keysight P5002B/200 is a 2-port vector network analyzer from the Streamline Series, engineered for portable RF measurements via high-speed Thunderbolt 3 connectivity. Despite its compact footprint, the P5002B delivers robust performance up to 9 GHz while reducing test setup size. Its lightweight design enables single-handed operation, making it ideal for space-constrained environments and mobile applications.
Key Features
- Frequency range: 9 kHz to 9 GHz
- 2-port configuration with Thunderbolt 3 interface (USB Type-C connectors)
- Compact, faceless design for portable testing
- Wide dynamic range and low trace noise for precision measurements
- Fast measurement speeds for efficient workflows
- Compatible with Keysight Electronic Calibration (ECal) modules
- Software-upgradeable with optional measurement applications
- No on-instrument data storage, suitable for classified environments
Applications
- Passive component characterization and testing
- Amplifier S-parameter measurements
- Frequency converter and mixer analysis
- Portable RF lab and field measurements
- Multi-site measurements via VNA cascading
Specifications
| Number of Ports | 2 |
| Maximum Frequency | 9 GHz |
| Minimum Frequency | 9 kHz |
| Type | PC Based |
| Dynamic Range | 146 dB |
| Series | P50xxB Streamline Series |
| Input Impedance | 50 Ω |
| Interface | Thunderbolt 3 |
