Keysight N9934C Cable and Antenna Analyzer
Request a quote
Keysight N9934C is a portable RF analyzer combining vector network analysis, spectrum analysis, and cable/antenna testing in one instrument with 3 kHz to 6.5 GHz range.
Product details
| Model | N9934C |
| Manufacturer | Keysight |
| Category | Vector Network Analyzers |
| Availability | Made to order |
Description
Overview
The Keysight N9934C FieldFox is a portable handheld RF analyzer designed for field testing of cables, antennas, filters, amplifiers, and signal analysis. It combines vector network analysis (VNA), spectrum analysis (SA), and cable and antenna test (CAT) capabilities in a single compact instrument with a 3 kHz to 6.5 GHz frequency range. The C-Series model provides enhanced performance for low-frequency measurements and extended VNA capability.
Key Features
- Multi-function analyzer: VNA, SA, and CAT in one portable unit
- Frequency range: 3 kHz to 6.5 GHz
- 6.5-inch anti-glare LCD display with LED backlight
- Built-in GPS receiver for precise location tracking
- Built-in variable voltage DC bias source
- Field-swappable rechargeable Li-ion battery (up to 4 hours runtime)
- Software-upgradeable frequency, bandwidth, and functionality via license
- Remote SCPI control over LAN and USB
- 5G and LTE OTA (Over-The-Air) support
- USB Power Sensor support
Applications
- RF cable and antenna testing
- Spectrum analysis and monitoring
- Vector network analysis and measurements
- 5G and LTE signal testing
- Radar signal detection and verification
- EMI/RFI field measurements
Included Accessories
- AC/DC power adapter
- Localized power cord
- Rechargeable Li-ion battery
- Soft carrying case with backpack and shoulder straps
- Quick Reference Guide
Specifications
| Frequency | 6.5 GHz |
| Series | C-Series |
| Backlight | Yes |
| Battery Life | 4 hrs. |
| Battery Type | Lithium-Ion |
| Connector Type | Type-N (f) |
| Dimensions | 11.5 x 7.4 x 3.2 in. |
| Display | 6.5" Transflective Color LCD-LED |
| Dynamic Range | 104 dB |
| Frequency Range | 3 kHz to 6.5 GHz |
| Function | SA |
| Includes | AC/DC adapter, Localized power cord, Rechargeable Li-ion battery, Soft carrying case with backpack and shoulder straps, Quick Reference Guide |
| Number of Ports | 2 |
| Operating Temperature Range | -10 to 55°C |
