Keysight N9933C Cable and Antenna Analyzer
Request a quote
Keysight N9933C is a portable RF analyzer for cables and antennas, 3 kHz to 4 GHz, with built-in GPS.
Product details
| Model | N9933C |
| Manufacturer | Keysight |
| Category | Vector Network Analyzers |
| Availability | Made to order |
Description
Overview
The Keysight N9933C FieldFox is a portable, battery-powered RF analyzer designed for field testing of cables, antennas, filters, amplifiers, and signal/spectrum analysis. Covering 3 kHz to 4 GHz with integrated GPS receiver for location tracking, it delivers professional-grade measurements in a lightweight handheld package. The C-Series model provides superior sensitivity at lower frequencies and extended vector network analysis capabilities.
Key Features
- 3 kHz to 4 GHz frequency coverage for comprehensive RF testing
- Superior signal sensitivity for lower frequency measurements down to 3 kHz
- Simultaneous measurement of all four S-parameters with high dynamic range
- Built-in GPS receiver for location tracking and field documentation
- High-resolution 6.5-inch LCD display with anti-glare coating and LED backlight
- Software-upgradeable capabilities via license keys
- Variable voltage DC bias source for active device testing
- Native support for 5G and LTE over-the-air (OTA) testing
- SCPI command interface for remote control and automation via LAN and USB
- Rugged construction meeting MIL-PRF-28800F Class 2, MIL-STD-810G, and IEC/EN 60529 standards
- Field-swappable rechargeable Li-ion battery providing up to 4 hours operation
- USB Power Sensor support for extended measurement capabilities
Applications
- Cable and antenna testing and troubleshooting
- Signal and spectrum analysis
- RF device characterization
- 5G and LTE field testing
- Field service and preventive maintenance
Included Accessories
- AC/DC power adapter
- Localized power cord
- Rechargeable Li-ion battery
- Soft carrying case with backpack and shoulder straps
- Quick Reference Guide
Specifications
| Frequency | 4 GHz |
| Series | C-Series |
| Backlight | Yes |
| Battery Life | 4 hrs. |
| Battery Type | Lithium-Ion |
| Connector Type | Type-N (f) |
| Dimensions | 11.5 x 7.4 x 3.2 in. |
| Display | 6.5" Transflective Color LCD-LED |
| Dynamic Range | 104 dB |
| Frequency Range | 3 kHz to 4 GHz |
| Function | SA |
| Includes | AC/DC adapter, Localized power cord, Rechargeable Li-ion battery, Soft carrying case with backpack and shoulder straps, Quick Reference Guide |
| Number of Ports | 2 |
| Operating Temperature Range | -10 to 55°C |
