Keysight N5262A Millimeter-Wave Test Set Controller
Request a quote
Keysight N5262A is a 4-port millimeter-wave test set controller for PNA/PNA-X network analyzers, supporting full S-parameter measurements with RF/LO signals up to 1.1 THz.
Product details
| Model | N5262A |
| Manufacturer | Keysight |
| Category | Vector Network Analyzers |
| Availability | Made to order |
Description
Overview
The Keysight N5262A is a 4-port millimeter-wave test set controller that provides the interface between up to four millimeter-wave test head modules and a PNA or PNA-X Series network analyzer. This controller delivers complete S-parameter measurement capabilities for comprehensive characterization of microwave and millimeter-wave components.
Key Features
- 4-port S-parameter test set functionality with millimeter-wave test head modules
- Supplies RF and LO signals to millimeter-wave test head modules
- Returns down-converted reference and test IF signals to PNA/PNA-X for processing and display
- Provides +12V bias to millimeter-wave head modules up to 1.1 THz
- Built-in ALC control for pulsed-RF measurements
Applications
- Multi-port millimeter-wave component testing and characterization
- Network analysis and S-parameter measurements of complex microwave systems
- Testing of passive and active devices including filters, amplifiers, mixers, and antennas
Specifications
| Form Factor | Benchtop |
