Keysight N4692A Electronic Calibration Module
Request a quote
Keysight N4692A electronic calibration module for fast and accurate network analyzer calibration. Frequency range 10 MHz to 40 GHz with NIST-traceable accuracy and USB control.
Product details
| Model | N4692A |
| Manufacturer | Keysight |
| Category | Vector Network Analyzers |
| Availability | Made to order |
Description
Overview
The Keysight N4692A is a microwave electronic calibration (ECal) module designed to streamline the calibration process for vector network analyzers. Unlike traditional mechanical calibration kits, ECal modules perform full two-port calibration with a single connection and significantly reduced operator interaction, making the process faster, more consistent, and less prone to errors.
Key Features
- Frequency range: 10 MHz to 40 GHz
- USB interface for direct control with Keysight PNA and ENA series network analyzers
- Full two-port calibration with a single connection
- Fast calibration compared to mechanical cal kits
- NIST-traceable accuracy comparable to mechanical methods
- Reduced connector wear extends equipment lifespan
- Reliable solid-state switching
Applications
- Microwave network analyzer calibration
- High-frequency impedance and S-parameter measurements
- Device characterization in RF/microwave labs
Specifications
| High Frequency (range) | 20GHz <= 50GHz |
| Low Frequency (range) | 1MHz <= 10MHz |
| Form Factor | Accessory |
