Keysight N4691B Electronic Calibration Module
Request a quote
Keysight N4691B is an electronic calibration module for vector network analyzers, supporting full two-port calibration via USB with reduced connector wear.
Product details
| Model | N4691B |
| Manufacturer | Keysight |
| Category | Vector Network Analyzers |
| Availability | Made to order |
Description
Overview
The Keysight N4691B is a microwave electronic calibration module that streamlines vector network analyzer calibration. Unlike traditional mechanical calibration kits, ECal modules use solid-state switching to deliver faster, more accurate, and more repeatable calibrations with minimal operator interaction.
Key Features
- Frequency range: 300 kHz to 26.5 GHz
- USB interface for direct control with PNA and ENA series network analyzers
- Full two-port calibration with a single connection
- Fast calibration reducing measurement time by more than 50% versus mechanical methods
- NIST traceable accurate calibrations
- Reduced connector wear
- Reliable solid-state switching
Applications
- Network analyzer calibration and verification
- RF and microwave component testing
- Production testing environments
Specifications
| High Frequency (range) | 20GHz <= 50GHz |
| Low Frequency (range) | 100kHz <= 1MHz |
| Form Factor | Accessory |
