Keysight N4690D 2-Port Microwave Electronic Calibration Module
Request a quote
Keysight N4690D is a precision 2-port microwave electronic calibration module for vector network analyzers, supporting type-N 50-ohm connectors from 300 kHz to 18 GHz via USB control.
Product details
| Model | N4690D |
| Manufacturer | Keysight |
| Category | Vector Network Analyzers |
| Availability | Made to order |
Description
Overview
The Keysight N4690D is a precision 2-port microwave electronic calibration (ECal) module designed for fast, accurate calibration of Keysight vector network analyzers. It supports type-N 50-ohm connectors and covers frequencies from 300 kHz to 18 GHz. With USB connectivity and firmware control, the N4690D reduces operator error and connector wear compared to traditional mechanical calibration kits. A plastic storage case is included for secure transport and storage.
Key Features
- Precision 2-port microwave ECal module with high accuracy
- Type-N 50-ohm connectors
- Frequency coverage: 300 kHz to 18 GHz
- Fast, easy, and accurate full two-port calibration
- Direct USB control from Keysight vector network analyzers
- Available in male/male, female/female, and male/female connector configurations
- Includes plastic storage case for protection
- Reduced connector wear and lower maintenance costs
Applications
- Vector network analyzer calibration
- Microwave component testing and characterization
- RF device verification
- Time domain and signal integrity analysis
Specifications
| High Frequency (range) | 10GHz <= 20GHz |
| Low Frequency (range) | 100kHz <= 1MHz |
