Keysight 85542B CalPod
Request a quote
Keysight 85542B is a thermal-vacuum calibration pod for network analyzers operating 500 MHz to 40 GHz with ±0.05 dB amplitude accuracy.
Product details
| Model | 85542B |
| Manufacturer | Keysight |
| Category | Vector Network Analyzers |
| Availability | Made to order |
Description
Overview
The Keysight 85542B is a temperature-characterized and thermal-vacuum environment calibration pod for rapid on-demand network analyzer recalibration. It operates from 500 MHz to 40 GHz and can be used without removing the device under test or reconnecting standards, which is particularly valuable in thermal-vacuum chamber testing and complex multi-port measurement environments.
Key Features
- Frequency: 500 MHz to 40 GHz
- Amplitude re-correction: ±0.05 dB (typical)
- Phase re-correction: ±1.5° (typical)
- Directivity re-correction: -38 dB (typical)
- Operates in thermal-vacuum environments
- Temperature range: -30°C to +80°C (operating)
- 2.92 mm connectors
Applications
- Thermal-vacuum chamber testing with automatic thermal effect correction
- Multi-port and multi-path network measurements
- Calibration in dynamic temperature environments
Specifications
| High Frequency (range) | 20GHz <= 50GHz |
