Anritsu MS2037C Vector Network Analyzer
Request a quote
Anritsu MS2037C is a handheld vector network analyzer covering 5 kHz to 15 GHz with integrated spectrum analyzer and 12-term error correction.
Product details
| Model | MS2037C |
| Manufacturer | Anritsu |
| Category | Vector Network Analyzers |
| Availability | Made to order |
Description
Overview
The Anritsu MS2037C VNA Master is a handheld vector network analyzer and spectrum analyzer covering 5 kHz to 15 GHz. It provides 2-port, 2-path vector-corrected measurements with 12-term error correction and features an integrated spectrum analyzer with ultra-low noise floor from 9 kHz to 15 GHz. Designed for field testing of RF and microwave systems across communications, aerospace, and defense applications.
Key Features
- Vector Network Analyzer: 5 kHz to 15 GHz frequency coverage
- Spectrum Analyzer: 9 kHz to 15 GHz with ultra-low noise floor
- 2-port, 2-path vector-corrected measurements with 12-term error correction
- User-defined Quad Display for viewing all 4 S-Parameters
- 350 μs/data point sweep speed
- Distance-To-Fault measurements (firmware V1.16 or higher)
- Spectrum analysis: Occupied Bandwidth, Channel Power, ACPR, C/I measurements
- Dynamic Range: >104 dB in 1 Hz RBW
- Burst Detect and PIM Hunting capabilities
Applications
- RF and microwave system field testing and troubleshooting
- Coaxial and waveguide measurements
- Spectrum monitoring and interference analysis
- Communications system validation on land, sea, air, and space platforms
- Distance-to-fault and cable fault location
Specifications
| High Frequency (range) | 10GHz <= 20GHz |
| Low Frequency (range) | 1kHz <= 100kHz |
| Connector Type | Type N-Female (Plug) |
