Keithley 2636B Source Measure Unit
Request a quote
Keithley 2636B is a dual-channel source measure unit with 6½-digit resolution, 0.1 fA to 10 A current range, 200 V capability, and embedded TSP test programming.
Product details
| Model | 2636B |
| Manufacturer | Keithley |
| Category | Source Measure Units |
| Availability | Made to order |
Description
Overview
The Keithley 2636B is a dual-channel source measure unit (SMU) from the Series 2600B family, designed for highly automated production test applications. It combines precision power supply, current source, digital multimeter, and electronic load capabilities with pulse generating features. The 2636B offers industry-leading 4-quadrant voltage/current sourcing and measurement with 6½-digit resolution across a dynamic range from 0.1 fA to 10 A and 100 nV to 200 V.
Key Features
- Dual-channel independent 4-quadrant voltage/current source and measurement
- 6½-digit resolution for precision characterization
- TSP (Test Script Processing) technology for embedded test programs without external controller
- TSP-Link expansion for daisy-chaining up to 64 channels in parallel test configurations
- Built-in web browser interface for remote control from any computer or device
- Keithley IVy mobile app support for Android-based I/V characterization
- Software emulation for Keithley 2400 SourceMeter compatibility
- Multiple connectivity options: USB 2.0, LXI-C, GPIB, RS-232, and digital I/O
- Optional ACS-Basic semiconductor characterization software
Applications
- Semiconductor device testing and production characterization
- Power device evaluation and parameter measurement
- Component quality assurance and burn-in testing
- Materials research and physical property analysis
- Automated parallel test systems for high-volume manufacturing
Specifications
| High Frequency (range) | 10MHz <= 100MHz |
| Number of Channels | 2 Channel |
| Maximum Current | 1.5 / 10 A |
| Maximum Voltage | 200 V |
| Maximum Power | 200 W |
| Series | 2600B Series |
| Connector Type | 25-pin female D |
| Dimensions | 3.50 x 8.37 x 17.50" |
| Display | Digital |
| Display Digits | 6.5 |
| Interface | GPIB, LAN / Ethernet, LXI, RS-232, USB |
| Maximum Input Voltage | 250 V |
| Operating Temperature Range | 0-50°C |
| Relative Humidity Range | 0-70% |
| Warranty | 1 Year |
