Keithley 2612B SourceMeter SMU Instrument
Request a quote
Keithley 2612B dual-channel SourceMeter SMU with 200V/1.5A DC output, 10A pulse, 100fA/100nV resolution, and integrated TSP automation.
Product details
| Model | 2612B |
| Manufacturer | Keithley |
| Category | Source Measure Units |
| Availability | Made to order |
Description
Overview
The Keithley 2612B is a dual-channel SourceMeter SMU instrument from the Series 2600B family. It combines a precision power supply, true current source, 6.5-digit DMM, and electronic load with pulse generating capabilities into a single integrated instrument. The 2612B is suitable for testing higher voltage and higher current devices, materials, components, and sub-assemblies, and features TSP technology for automated test program execution with industry-leading throughput.
Key Features
- Dual-channel 4-quadrant voltage/current source and measure with 6.5-digit resolution
- Maximum voltage: 200V; Maximum current: 1.5A DC / 10A pulse per channel
- Measurement resolution: 100 fA (current) / 100 nV (voltage)
- Wide dynamic range across product family: 10A pulse to 0.1 fA, 200V to 100 nV
- Built-in web browser-based software for remote control from any computer worldwide
- Keithley IVy mobile app support for Android plug-and-play I-V testing
- TSP (Test Script Processing) technology for high-speed test automation (190%+ faster than traditional PC-to-instrument communication)
- TSP-Link expansion technology for multi-channel parallel test without a mainframe
- Connectivity: USB 2.0, LXI-C, GPIB, RS-232, and digital I/O
- Software emulation for Keithley 2400 SourceMeter SMU for legacy test code migration
- Optional ACS-Basic semiconductor component characterization software
Applications
- Dual-channel I-V characterization of semiconductors and components
- Automated production test and high-volume parallel test
- Higher voltage and higher current device testing
- Materials and sub-assembly characterization
- Research and development testing
Specifications
| High Frequency (range) | 10MHz <= 100MHz |
| Number of Channels | 2 Channel |
| Maximum Current | 1.5 / 10 A |
| Maximum Voltage | 200 V |
| Maximum Power | 200 W |
| Series | 2600B Series |
| Connector Type | 25-pin female D |
| Dimensions | 3.50 x 8.37 x 17.50" |
| Display | Digital |
| Interface | GPIB, LAN / Ethernet, LXI, RS-232, USB |
| Maximum Input Voltage | 250 V |
| Operating Temperature Range | 0-50°C |
| Relative Humidity Range | 0-70% |
| Warranty | 1 Year |
