Vitrek PA921UT Power Analyzer
Request a quote
Vitrek PA921UT is a high-precision power analyzer with 0.024% accuracy, 2MHz bandwidth, touchscreen, and modular design for flexible power measurements.
Product details
| Model | PA921UT |
| Manufacturer | Vitrek |
| Category | Power Analyzers |
| Availability | Made to order |
Description
Overview
The Vitrek PA921UT is a high-precision power analyzer from the PA920 Series, featuring a single ultra-precision UT channel card. Equipped with a full-color touchscreen interface, it enables users to quickly configure settings, custom screens, and interface commands. The mainframe is designed for modular expansion with up to 8 available channel combinations to meet diverse power analysis needs.
Key Features
- 0.024% power accuracy (industry-leading)
- 2MHz bandwidth with 24-bit sampling
- 1250Vrms maximum continuous voltage input
- Ultra-precision dual shunt current input (0 to 32A continuous, 150A peak inrush)
- 0.1µA current resolution
- 100 full precision readings per second
- Handles 5MHz waveforms with crest factors up to 100:1
- Full-color touchscreen with easy configuration
- Modular channel card design for flexible expansion
Applications
- Power factor measurement and analysis
- Low phase angle and high crest factor load testing
- Electrical device characterization and validation
- Energy efficiency studies and power consumption analysis
- Industrial equipment performance monitoring
Included Accessories
- PA920 mainframe
- 1 UT channel card (ultra-precision dual shunt)
- Power cord
- Operating manual
- Supplemental applications software
Specifications
| Maximum AC Voltage | 2000 V |
| Maximum AC Current | 150 A |
| Series | PA920 Series |
| Display | 7" Color LCD Touch |
| Interface | USB, LAN, RS-232 |
