Tektronix P5100A-PKG High-Voltage Probe 10-Pack

Overview

The Tektronix P5100A-PKG is a 10-pack bundle of high-voltage passive oscilloscope probes designed for low input capacitance measurements at higher frequencies. Each P5100A probe is rated for 2.5 kV and features 500 MHz bandwidth, making the bundle cost-effective for labs and test facilities requiring multiple probes for concurrent measurements.

Key Features

• 10-pack bundle of P5100A probes
• DC to 500 MHz bandwidth per probe
• 2.5 kV peak / 1 kV RMS CAT II rated per probe
• 100X attenuation with readout coding
• Low input capacitance (2.5 pF nominal per probe)
• Compensable to match 7-30 pF input oscilloscope capacitances
• Each probe includes variety of screw-on accessories

Applications

• Power supply design and analysis
• Motor drive design and testing
• Electronic ballast circuits
• Power semiconductor measurements
• Switch-mode control circuits
• UPS systems
• Power converters

Included Accessories

• Large hook tip per probe
• Small hook tip per probe
• 6 inch ground lead per probe
• 18 inch ground lead per probe
• Ground spring per probe
• Crocodile clip per probe
• Adjustment tool
• Color bands
• Instruction manual
