Keysight 8473D/003 Planar-Doped Barrier Diode Detector

Overview

The Keysight 8473D/003 is a high-performance planar-doped barrier diode detector with positive polarity output, designed for RF and microwave measurement applications. This detector features a gallium arsenide detecting element with excellent frequency response flatness and temperature stability across an extended frequency range from 10 MHz to 33 GHz.

Key Features

• Frequency range: 10 MHz to 33 GHz
• Positive polarity output configuration
• Flat frequency response: ±0.25 dB to 14 GHz, ±0.4 dB to 26.5 GHz, ±1.25 dB to 33 GHz
• Maximum SWR: 1.2 to 14 GHz, 1.4 to 26.5 GHz, 3.0 to 33 GHz
• Low-level sensitivity: > 0.5 mV/µW
• Maximum operating input power: 200 mW
• Short-term maximum input power: 1 W (< 1 minute)
• Input connector: 3.5 mm male
• High ESD resistance and rugged construction

Applications

• RF and microwave power measurement
• Signal detection and leveling
• Automatic gain control systems
• Test and measurement equipment
