Viavi OSA-501M Optical Spectrum Analyzer
Request a quote
Viavi OSA-501M optical spectrum analyzer with 12.5 GHz channel drop capability, featuring true in-band OSNR measurement for ROADM-based DWDM networks.
Product details
| Model | OSA-501M (2281/91.23) |
| Manufacturer | Viavi |
| Category | Network & Fiber Optic Test |
| Availability | Made to order |
Description
Overview
The Viavi OSA-501M is a full-featured optical spectrum analyzer designed for DWDM and CWDM system testing and characterization. With a tuning range of 1250 to 1650 nm, it supports networks operating at speeds up to 100 Gbps and is particularly well-suited for ROADM-based systems requiring true in-band OSNR measurement capabilities.
Key Features
- Optical Polarization Splitting (OPS) method for true in-band OSNR measurement in ROADM networks
- Wide tuning range of 1250 to 1650 nm for DWDM and CWDM compatibility
- 12.5 GHz channel drop capability for single-channel isolation and in-depth signal analysis
- PMD testing software with fixed analyzer method
- Built-in optical component test applications for laser diodes, LEDs, and optical amplifiers
- Internal online wavelength calibration with no recalibration required
- Lab-grade optical performance in field-modular design
Applications
- Installation, maintenance, and upgrade testing of DWDM and CWDM systems
- OSNR measurement in ROADM-based agile optical networks
- Automated DWDM passive and active component characterization
- System verification testing against preset limits
- ROADM configuration verification in agile optical networks
Specifications
| Form Factor | Modular |
