Viavi OSA-500M Optical Spectrum Analyzer
Request a quote
Viavi OSA-500M is a standard optical spectrum analyzer for CWDM and DWDM system testing with 1250–1650 nm wavelength range and lab-grade performance.
Product details
| Model | OSA-500M (2281/91.20) |
| Manufacturer | Viavi |
| Category | Network & Fiber Optic Test |
| Availability | Made to order |
Description
Overview
The Viavi OSA-500M is a standard optical spectrum analyzer designed for spectral measurements in CWDM systems in access networks and DWDM systems in high-speed backbone networks with data rates up to 100 Gbps. It provides high filter selectivity and laboratory-grade optical performance across the full band from 1250 to 1650 nm in a field-modular design. The OSA-500M is suitable for all optical coarse and dense wavelength division multiplexing applications.
Key Features
- Full-band measurement range from 1250 to 1650 nm
- High filter selectivity with lab-grade optical performance
- Field-modular design for easy deployment and integration
- Suitable for CWDM and DWDM systems down to 33 GHz channel spacing
- Built-in optical component test applications for laser diodes, LEDs, and optical amplifiers
- Internal online wavelength calibration requiring no recalibration
Applications
- DWDM and CWDM system testing during installation, maintenance, and network upgrade
- Automated DWDM passive and active component testing
- System verification testing according to preset limits
- Full-band optical spectrum analysis for ONT platform, MTS-8000/T-BERD 8000, and MTS-6000/T-BERD 6000
Specifications
| Form Factor | Modular |
