Viavi OMK-38V2 High-Power Optical Test Kit
Request a quote
Viavi OMK-38V2 is a pocket-sized high-power single-mode optical test kit with broadband meter (-50 to +26 dBm), dual-wavelength source (1310/1550 nm), and Bluetooth for CATV and amplified DWDM test...
Product details
| Model | OMK-38V2 |
| Manufacturer | Viavi |
| Category | Network & Fiber Optic Test |
| Availability | Made to order |
Description
Overview
The Viavi OMK-38V2 SmartPocket V2 is a next-generation portable optical test kit engineered for high-power single-mode fiber optic networks. This kit features a broadband optical power meter capable of measuring power levels from -50 to +26 dBm paired with a dual-wavelength laser light source (1310/1550 nm), making it specifically suited for CATV and amplified DWDM applications.
Key Features
- Broadband power meter with extended range (-50 to +26 dBm) for high-power applications
- Dual-wavelength light source (1310/1550 nm) for single-mode testing
- Fiber tracing with tone detection for optical light source identification
- Storage for over 1000 test results with PC download capability
- Bluetooth Low Energy connectivity to VIAVI Mobile Tech App
- Multiple power options: alkaline AA, NiMH AA rechargeable, or AC adapter
- 3-year recalibration period and instant-on operation
Applications
- CATV and amplified DWDM network testing up to +26 dBm
- High-power level measurements in service provider and telecom networks
- Telecom and military-grade network applications
- Comprehensive single-mode fiber network installation and commissioning
Included Accessories
- VIAVI OLS-35V2 dual-wavelength light source
- VIAVI OLP-38V2 high-power optical power meter
- Soft carrying bag
- Universal AC power adapter
- Neck strap and quick start guide
- Dry AA batteries
Specifications
| Ready when you need it - ultra-high reliability and high availability | Dependable, German design Designed with outdoor environment in mind Low power consumption for extended continuous use Instant On – no boot time |
| Easy to use | High-Visibility backlit graphical display with context-sensitive softkey No setup ‘OptiChek’ measurement mode Fast Auto-λ, Multi-λ mode (~ 1 sec) Clear pass/fail information Automatic upload of results via VIAVI Mobile Tech application |
| OMK-38V2 | A high power SM kit with an OLS-35V2 and an OLP-38V2 for CATV and amplified DWDM applications up to +26 dBm. |
| Light Source Wavelengths | 1310, 1550 nm850, 1300, 1310, 1550 nm1310, 1550 nm |
| Light Source Output Power | Typ. -3 dBmTyp. -20 dBm / -3 dBmTyp. -3 dBm |
| Optical Power Meter Power Range | -65 to +10 dBm-65 to +10 dBm-50 to +26 dBm |
| Model / Part Number | Description |
| OMK-38V2 | Service Provider High-Power Plus - SM Test Kit |
