Viavi OLP-38V2 Optical Power Meter
Request a quote
Viavi OLP-38V2 is a high-power optical power meter for CATV and amplified DWDM systems, measuring up to +26 dBm with 1 nm wavelength resolution.
Product details
| Model | OLP-38V2 |
| Manufacturer | Viavi |
| Category | Network & Fiber Optic Test |
| Availability | Made to order |
Description
Overview
The Viavi OLP-38V2 is a compact, pocket-sized optical power meter designed for installation and maintenance of fiber optic networks. As a high-power variant of the OLP-3xV2 series, it supports measurements up to +26 dBm, making it ideal for CATV HFC systems with analog RF transmission and amplified DWDM applications.
Key Features
- 1 nm incremental wavelength settings for precise measurements
- Filtered InGaAs detector optimized for high-power applications (up to +26 dBm)
- Universal optical interface supports all 2.5 mm connectors with optional 1.25 mm adapter
- Fiber tracing function detects optical light source tones from SmartPocket V2 sources
- Storage for over 1000 test results with PC download capability
- Bluetooth connectivity to VIAVI Mobile Tech App for automatic result upload
- Three-way powering: alkaline AA batteries, NiMH rechargeable, or AC power adapter
- High-visibility backlit graphical display with context-sensitive softkeys
- 3-year recalibration period
Applications
- CATV HFC network testing with analog RF transmission
- Amplified DWDM system verification and monitoring
- Optical power level measurement for high-power installations
- Link insertion loss testing in single mode and multimode networks
- Enterprise LAN, access, metro, and FTTx network deployment
Specifications
| Ready when you need it – ultra-high reliability and high-availability | Dependable, German design Designed with outdoor environment in mind Over 70 hours continuous use with 2x AA Alkaline batteries Instant On – no boot time |
| Easy to use | High-Visibility backlight graphical display with context-sensitive softkeys No setup “OptiChek” measurement mode Fast Auto-λ, Multi-λ mode when paired with SmartPocket V2 optical light sources Clear pass/fail information Automatic upload of results via VIAVI Mobile Tech App |
| OLP-38V2 | (filtered InGaAs) is a higher-power version (up to +26 dBm) for CATV HFC (with analogue RF transmission) or amplified DWDM systems |
| Model / Part Number | Description |
| OLP-38V2 | High Power PM UPP Adapter; calib. at 850/980/1310/1550/1625 with BT |
