Viavi MORL-A11308-MBID-M101 Multimode IL/RL Test Meter

Overview

The Viavi MORL-A11308-MBID-M101 is a multimode insertion loss and return loss (IL/RL) test meter for optical fiber characterization. Supporting 850/1300nm wavelengths on 50μm OM3 multimode fiber with bidirectional testing capability, this module integrates with the Viavi MAP-Series platform for modular testing configurations. It features FC/APC connector compatibility and provides accurate measurement for quality control in manufacturing and field deployment.

Key Features

• Bidirectional insertion loss and return loss measurement
• 850/1300nm wavelength support for OM3 multimode fiber
• 50μm core diameter specifications
• FC/APC connector interface
• Integration with Viavi MAP-Series modular platform
• Port mapping verification for continuity and polarity
• Supports multifiber connector testing including MPO/MTP

Applications

• Testing insertion loss and return loss of optical connectors and cable assemblies
• Quality assurance in structured cabling installations
• Verification of optical splitter performance
• Continuity and polarity verification of multifiber assemblies
• Production test environments for optical components
