EXFO FTB-7300D-023B OTDR
Request a quote
FTB-7300D-023B OTDR with 1 m shortest event dead zone, dynamic range to 38 dB, and rapid 45-second acquisition for metro/access networks.
Product details
| Model | FTB-7300D-023B |
| Manufacturer | EXFO |
| Category | Network & Fiber Optic Test |
| Availability | Made to order |
Description
Overview
The EXFO FTB-7300D-023B is a medium-haul dual-wavelength OTDR module that delivers exceptional performance for metro, access, and fiber-to-the-home (FTTH) network testing. With an industry-leading 1 m event dead zone, dynamic range up to 38 dB, and lightning-fast acquisition in 45 seconds, this module enables field technicians to characterize splices, connectors, splitters, and breaks along fiber links with exceptional speed and accuracy.
Key Features
- Dual wavelength operation at 1310 and 1550 nm
- 1 m event dead zone — shortest in the industry
- Dynamic range up to 38 dB at 20 μs
- Lightning-fast trace acquisition: full averaging in 45 seconds
- Market-leading linearity of ±0.03 dB/dB for accurate event characterization
- EXFO Universal Interface (EUI) connector: compatible with both UPC and APC connectors
- Passive optical network (PON) testing capability per ITU-T G.983.3
Applications
- Metro and access network testing
- Fiber-to-the-home (FTTH) and fiber-to-the-premises (FTTP) installations
- Passive optical network (PON) testing at 1310, 1490, and 1550 nm
- Splitter characterization in high-port-count deployments
Specifications
| FTB-7200D-XXX | 1310 ± 20/1550 ± 2035/3436/351/15/6 (4/4)⁶ |
| FTB-7200D-023B | SM short-haul OTDR module, 1310/1550 nm (9/125 µm) |
| FTB-7300D-234B | SM medium-haul OTDR module, 1310/1550/1625 nm (9/125 µm) |
| Example | FTB-7300D-234B-EI-EUI-89-VFL |
