Teledyne LeCroy T3PS43203P Quad Output DC Power Supply

Overview

The Teledyne LeCroy T3PS43203P is a four-channel programmable DC power supply with 217W maximum output power. Part of the T3PSx3200P Series, it combines precise voltage and current control with advanced monitoring and data logging capabilities. The supply is designed for applications requiring independent multi-channel power distribution with flexible configuration options.

Key Features

• Four independent output channels: CH1/CH2 0-32V/0-3A, CH3 0-5V/0-1A, CH4 0-15V/0-1A
• High programming resolution of 1 mV/0.1 mA and readback resolution of 0.1 mV/0.1 mA
• Ultra-low ripple noise ≤350 μVrms/≤2 mArms with transient recovery ≤50 μs
• Tracking function for automatic series/parallel operation without external wiring
• Independent on-off switch for each channel
• Multiple display modes for setting values, measurement values, and waveform visualization
• Monitor function with alarm and automatic output shutdown protection
• Output recorder function storing voltage/current data as .REC or .CSV files

Applications

• Multi-channel circuit testing and verification
• Educational laboratory work and training
• Component characterization and burn-in testing
• System integration and development
