Teledyne LeCroy T3PS30063P Triple Output DC Power Supply

Overview

The Teledyne LeCroy T3PS30063P is a triple-output programmable DC power supply with a maximum power output of 385W. It features three isolated channels with independent on-off control: two adjustable channels (0–30V/0–6A) and one channel with fixed output options (1.8V, 2.5V, 3.3V, or 5V at 5A max, 3A via USB). The supply includes comprehensive monitoring, recording, and display functions for professional testing and development work.

Key Features

• Three isolated outputs with independent on-off control
• Two adjustable channels support series and parallel operation without external wiring
• Constant voltage and constant current operation on adjustable channels
• Electronic load functionality (CV, CC, CR modes) on adjustable channels
• Low ripple noise ≤1 mVrms with transient recovery time ≤100 μs
• High-resolution programming and readback (1 mV/0.1 mA)
• Sequential output function with 8 built-in template waveforms
• 10 sets of memory for sequence, delay, recorder, and panel settings
• USB output terminal for powering external devices
• Standard interfaces: RS-232, USB, LAN, and external I/O

Applications

• Research and development of electronic circuits and systems
• Production testing and quality assurance
• Educational use in laboratory environments
• Device characterization and validation

Included Accessories

• Quick Start Guide
• Power cords (3)
• Short bar connector
• 13-pin terminal block
• Test leads (3)
