ITECH IT6333A Triple Output DC Power Supply
Request a quote
ITECH IT6333A is a programmable triple-output DC power supply with 2×60V/3A and 1×5V/3A outputs, 1mV/1mA resolution, and series/parallel/track operation modes.
Product details
| Model | IT6333A |
| Manufacturer | ITECH |
| Category | Multiple Output DC Supplies |
| Availability | Made to order |
Description
Overview
The ITECH IT6333A is a programmable triple-channel DC power supply from the IT6300A series, offering independent control of three separate outputs. Each output voltage and current can be set from 0 to its maximum rating, and the unit supports series connection, parallel connection, and synchronous functions across channels. With high-resolution 1mV / 1mA control and built-in remote sense capability, the IT6333A delivers accurate multi-rail power delivery for complex test scenarios.
Key Features
- Triple output with independent voltage and current adjustment on all channels
- Series, parallel, and track (synchronized) operation modes
- Simultaneous display of voltage and current for all three channels
- Compact 1/2 2U rackmount form factor
- VFD display with function keys and LED indicators
- Cursor-based digital step value adjustment for precise control
- Independent output switch control per channel
- High accuracy, resolution (1mV / 1mA), and stability
- Remote measurement function with online pressure-drop compensation
- Comprehensive protection functions (overvoltage, overcurrent, overtemperature)
- Intelligent fan control for low-noise operation
- Built-in RS232 and USB communication interfaces
Applications
- Multi-rail power supply testing for digital and analog circuits
- Power electronics research and development
- Electronic component validation and burn-in testing
- Industrial control system commissioning and maintenance
Specifications
| Number of Outputs | Triple Output |
| Output Voltage | 5V, 60V x 2 |
| Output Current | 3A x 3 |
| Power Rating | 180 W |
| Input Voltage | 110/220 VAC |
| Interface | USB, RS-232 |
| Special Features | Series, Parallel Modes |
| Display | VFD |
| Series | IT6300A Series |
| Includes | Power cord, USB cord, Factory calibration certificate |
| Mounting Type | Bench Top |
| Programmable | Yes |
