Aim TTi QL564TP SII Triple Output DC Power Supply

Overview

The Aim TTi QL564TP SII is a precision 242-watt triple-output DC power supply designed for laboratory and system applications requiring exceptional accuracy, low noise, and comprehensive digital control. It features linear regulation technology and a highly intuitive user interface combining numeric entry and rotary jog control.

Key Features

• Triple outputs: two 0–56V/2A ranges, one 0–25V/4A range, and one 1–6V/3A auxiliary output
• 242 watts total output power
• Exceptional precision with 1mV resolution courtesy of 16-bit DACs
• Very low output noise: less than 350µV RMS in CV mode, 20µA RMS in CI mode
• Linear regulation technology with recovery time better than 50µs
• Remote and local sense capability for perfect load regulation
• Numeric and rotary jog wheel control
• Up to 50 non-volatile memory settings
• Comprehensive protection with OVP and OCP trips
• Safety binding-post terminals accepting 4mm safety plugs
• Digital interfaces: USB, RS-232, GPIB, LAN with LXI compliance
• Compact bench footprint; modular for rack mounting

Applications

• Laboratory bench testing and equipment calibration
• Precision circuit development and prototyping
• Telecommunications and sensitive receiver testing
• Automated test systems via LAN, USB, GPIB, or RS-232 control
• Calibration source for hand-held multimeters
