Keysight B1505AP Power Device Analyzer
Keysight B1505AP is a pre-configured Power Device Analyzer for characterizing high-power devices up to 10kV and 1500A with complete measurement solution.
Product details
| Model | B1505AP |
| Manufacturer | Keysight |
| Category | LCR Meters |
| Availability | Made to order |
Description
Overview
The Keysight B1505AP is a pre-configured Power Device Analyzer / Curve Tracer providing ready-to-use solutions for power device characterization. Each package includes all required B1505A hardware and software—mainframe, cables, test fixture, and software—for evaluating discrete power devices. The B1505AP uses the same mainframe and modules as the B1505A and may be expanded identically.
Key Features
- Pre-configured packages for immediate use
- Maximum voltage: up to 10kV (configuration dependent)
- Maximum current: up to 1500A (configuration dependent)
- Pulse resolution: 10µs
- Capacitance measurement: up to ±3 kV DC bias
- Compatible with B1505A modules for future expansion
- Test fixture accommodates diverse power device package types
- Built-in interlock mechanism for safe high-voltage/high-current operation
Included Components
Each B1505AP package includes mainframe, measurement modules, test fixture with customizable modules, interconnecting cables, and EasyEXPERT group+ software for device characterization and analysis.
Applications
- Power MOSFET characterization
- IGBT evaluation
- Power diode testing
- High-voltage and high-current device characterization
- Device curve tracing and parameter extraction
Specifications
| Maximum Voltage | 10kV |
| Maximum Current | 1500A |
| Pulse Resolution | 10µs |
| Capacitance Measurement Bias Range | ±3 kV DC |
