GW Instek LCR-8220 High Frequency LCR Meter
Request a quote
GW Instek LCR-8220 measures DC to 20MHz with 0.08% accuracy, 7-inch color display, and supports USB/GPIB/RS-232 interfaces for component testing.
Product details
| Model | LCR-8220 |
| Manufacturer | GW Instek |
| Category | LCR Meters |
| Availability | Made to order |
Description
Overview
The GW Instek LCR-8220 is a high-frequency LCR meter from the LCR-8200 series, designed for measuring passive component characteristics from DC to 20MHz. It features a 7-inch LCD color display and 0.08% basic accuracy. Measurement results can be presented numerically or graphically, with up to four parameters displayed simultaneously from 17 selectable measurement options. This versatile instrument supports research, engineering, and production testing of passive components.
Key Features
- Test frequency: DC, 10Hz - 20MHz with 6-digit resolution (±0.0007%)
- 7-inch LCD color display (800x480)
- 0.08% basic measurement accuracy
- Simultaneous display of up to four measurement parameters from 17 selectable options
- 15-step list measurement capability
- Two-curve sweep mode for graphical analysis
- Internal DC bias voltage: ±12V
- USB storage function in graphics mode
- ALC (Automatic Level Control) function
- Multiple interfaces: RS-232C, USB host/device, LAN, GPIB, and Handler
- Selectable output impedance: 25Ω or 100Ω
Applications
- Passive component characterization in research and development
- Quality assurance testing in production environments
- Impedance and capacitance measurement for component validation
- Component frequency response analysis and sweep testing
Specifications
| High Frequency (range) | 10MHz <= 100MHz |
