GW Instek LCR-8205 High Frequency LCR Meter

Overview

The GW Instek LCR-8205 is a 5MHz high-frequency LCR meter from the advanced LCR-8200 Series. It delivers measurements up to 5MHz with 0.08% basic accuracy and 6-digit resolution, featuring a 7-inch color LCD display and comprehensive measurement capabilities.

The LCR-8205 combines high precision with practical functionality, supporting numerical and graphical measurement result presentation. It features standard interfaces including USB, RS-232C, LAN, GPIB, and Handler, making it suitable for R&D, engineering, and production testing applications.

Key Features

• Test frequency: DC, 10 Hz to 5 MHz
• 7-inch LCD color display (800×480 resolution)
• 0.08% basic accuracy with 6-digit measurement resolution
• Output impedance: 25Ω or 100Ω (selectable)
• Four simultaneous measurement results from 17 selectable parameters
• 15-step list measurement with frequency, voltage, current, and DC bias control
• Two-curve sweep measurement for graphical analysis
• Test signal level: AC voltage 10mV to 2Vrms, AC current 100μA to 40mArms, DC 1Vdc
• Internal DC bias voltage: ±12V
• Auto Level Control (ALC) function
• USB storage for measurement data
• Standard interfaces: RS-232C, USB host/device, LAN, GPIB, and Handler
• Universal power input (AC 100V~240V, 50/60Hz)
• Compact size: 346(W) × 145(H) × 335(D) mm; approximately 3.3 kg

Measurement Parameters

• Impedance (Z)
• Inductance (Ls / Lp)
• Capacitance (Cs / Cp)
• AC Resistance (Rs / Rp)
• Quality Factor (Q)
• Dissipation Factor (D)
• Admittance (Y)
• Conductance (G)
• Reactance (X)
• Phase Angle (θd / θr)
• Susceptance (B)
• DC Resistance (Rdc)

Applications

• Research and development of passive components
• Engineering validation and design verification
• Production quality control and testing
• Component characterization and analysis
