GW Instek LCR-6300 High Precision LCR Meter

Overview

The GW Instek LCR-6300 is a high-precision LCR meter from the LCR-6000 series, designed for R&D, production testing, incoming quality control, and component verification. It features a compact 2U height, ½ rack design, making it suitable for both bench-top and system rack installations.

The meter combines advanced measurement capabilities with user convenience, offering 0.05% basic accuracy, a 3.5-inch color LCD display, and rich functionality for passive component testing across frequencies from 10 Hz to 300 kHz.

Key Features

• Frequency range: 10 Hz to 300 kHz with ±0.01% frequency accuracy
• 3.5-inch color LCD with opulent display parameters
• Basic accuracy: 0.05%
• Measurement speed up to 25ms (maximum)
• Four simultaneous measurement parameters display (primary, secondary, and two monitoring parameters)
• Full frequency range or spot OPEN/SHORT zero methods
• 16 major/secondary parameter measurement combinations
• DC resistance measurement with internal ±2.5V DC bias voltage
• PASS/FAIL judgment with automatic bin sorting (9BIN + 1AUX)
• Auto Level Control (ALC) function for MLCC testing
• 10 steps of listed tests with frequency, voltage, and current parameters
• 10 memory sets for test criteria storage
• 10,000 measurement result storage capability
• Standard interfaces: RS-232C, Handler, and USB host
• Compact 2U, ½ rack size for space-saving installation

Applications

• Quality Control and Incoming Inspection
• Research and Development
• Low-Frequency Filter and Coil Design
• Educational Labs and Training

Included Accessories

• Safety sheet
• Power cord
• Test fixture LCR-06A
