GW Instek LCR-6020
Request a quote
GW Instek LCR-6020 is a high-precision LCR meter with 0.05% accuracy, 10Hz-20kHz frequency, and compact 2U design for benchtop or system rack integration.
Product details
| Model | LCR-6020 |
| Manufacturer | GW Instek |
| Category | LCR Meters |
| Availability | Made to order |
Description
Overview
The GW Instek LCR-6020 is a high-precision LCR meter for testing and measuring passive components in research, development, and production environments. With a compact 2U half-rack design, 0.05% basic accuracy, and 10Hz to 20kHz frequency range, it is suitable for benchtop or system rack integration in quality control and component assessment applications.
Key Features
- 3.5" color LCD display simultaneously showing up to four parameters
- 0.05% basic accuracy with consecutive frequency selection from 10Hz to 20kHz
- Measuring speed up to 25ms with PASS/FAIL judgment display
- Full frequency range or spot OPEN/SHORT zero methods without changing fixtures
- DC resistance measurement with internal ±2.5V adjustable bias voltage
- Auto Level Control (ALC) function for MLCC testing
- 10-step testing program for varied frequency, voltage, and current criteria
- BIN sorting function (9 BIN + 1 AUX) for automated sorting integration
- 10 memory sets and 10,000 measurement storage capability
- Standard interfaces: RS-232C, Handler, USB Host/Device
- Compact 2U, 1/2 rack design for benchtop or automated equipment
Applications
- Research and development of passive components
- Production testing and quality control
- Low-frequency filter and coil design
- Automated sorting and material verification
Specifications
| High Frequency (range) | 1kHz <= 100kHz |
