Megger MIT320 Insulation and Continuity Tester
Request a quote
Megger MIT320 is a handheld insulation and continuity tester with selectable test voltages (250V/500V/1000V), backlight display, and measurement capability up to 1MΩ.
Product details
| Model | MIT320 |
| Manufacturer | Megger |
| Category | Insulation Resistance & Megohmmeters |
| Availability | Made to order |
Description
Overview
The Megger MIT320 is a digital insulation and continuity tester designed for electrical maintenance and testing applications. It features a combined digital and analogue display with large 20mm characters for clear readability in both bright and dark conditions, complemented by a backlight function. The tester is suitable for Installation Category III applications up to 440V.
Key Features
- Selectable test voltages: 250V, 500V, and 1000V
- Insulation resistance measuring range: 10Ω to 1MΩ
- Continuity testing capability with 1.5mA short circuit current
- AC/DC voltage measurement: 0–600V
- Digital/analogue display with backlight for visibility in dark environments
- High accuracy: ±5% ±2 digits up to 100kΩ at 20°C
- Auto power down feature to extend battery life
Applications
- Electrical installation testing and maintenance
- Equipment commissioning and verification
- Routine insulation resistance checks
- Continuity verification of circuits and connections
Included Accessories
- Test lead set with crocodile clips (1002-001)
- SP4F Switch probe (6220-809)
Specifications
| Series | MIT300 Series |
