GW Instek GPT-9602 AC/DC Withstanding Voltage Tester

Overview

The GW Instek GPT-9602 is a 100VA AC withstanding voltage tester capable of performing both AC and DC high-voltage withstanding testing. It is part of the GPT-9600 Series, which features a high-efficiency PWM amplifier platform designed to deliver stable voltage output despite input AC voltage fluctuations. The instrument is equipped with comprehensive safety features including zero-crossing turn-on operation and an interlock function to protect operators from high-voltage hazards.

Key Features

• 100VA AC maximum power output
• 5kV AC maximum voltage output with true RMS current measurement
• 6kV DC maximum voltage capability (select models)
• 240 x 48 ice blue dot matrix LCD display
• Zero-crossing turn-on operation to protect test devices
• Safety INTERLOCK function to prevent accidental high-voltage contact
• PWM switching amplifier for efficient and reliable testing
• Automatic input source switching for universal input voltage compatibility
• Remote terminal and Signal I/O interfaces for external control
• Two-year warranty

Applications

• High-voltage withstanding and breakdown testing of electronic components
• AC and DC voltage stress testing in manufacturing quality control
• Safety compliance verification for industrial equipment
• Voltage testing in laboratories and service facilities

Included Accessories

• Quick Start Guide
• Power Cord
• Interlock Key
• Remote Terminal Connector
• GHT-114 Test Lead
