Fluke FLUKE-1587/I400 FC Insulation Multimeter
Request a quote
Fluke 1587 FC with i400 current clamp measures insulation to 2 Gigohm at up to 1000V and AC current to 400A with Fluke Connect wireless connectivity.
Product details
| Model | FLUKE-1587/I400 FC |
| Manufacturer | Fluke |
| Category | Insulation Resistance & Megohmmeters |
| Availability | Made to order |
Description
Overview
The Fluke 1587 FC is a comprehensive dual-function insulation multimeter combined with the Fluke i400 AC current clamp in one complete kit. The multimeter integrates a digital insulation tester with a full-featured true RMS digital multimeter, while the i400 clamp enables non-intrusive AC current measurements up to 400A. This kit provides complete diagnostic capability for electrical maintenance without breaking circuits.
Key Features
Insulation Multimeter
- Insulation test range: 0.01 to 2.0 Gigohm
- Insulation test voltages: 50V, 100V, 250V, 500V, 1000V
- True RMS AC/DC voltage, DC millivolts, AC/DC milliamps, resistance, and continuity
- VFD low-pass filter for accurate motor drive measurements
- Capacitance, diode test, temperature, Min/Max, and frequency measurements
- Live circuit detection prevents insulation test if voltage >30V is detected
- Auto-discharge of capacitive voltage
- Large backlit 6000-count display
- CAT III 1000V, CAT IV 600V safety rating
i400 Current Clamp
- Measures AC current from 1A to 400A
- 1 mA per Ampere output for easy reading
- Maximum conductor diameter: 32 mm
- CAT III 1000V, CAT IV 600V safety rating
- Compact design for utility in tight spaces
- 1-year warranty
Advanced Features
- PI/DAR timed ratio tests for identifying moisture and contamination in insulation
- Fluke Connect wireless connectivity for mobile app data sharing and analysis
- TrendIt graphs for visualization of insulation degradation
- Temperature compensation via Fluke Connect app
- Historical tracking and trending via Fluke Connect Assets (sold separately)
- Auto power off to save battery
- 3-year warranty on multimeter
Applications
- Motor and generator condition assessment
- Cable and switchgear diagnostics
- Current monitoring without circuit interruption
- Preventive maintenance and condition-based monitoring
- Field troubleshooting with wireless data logging
Included Accessories
- Fluke 1587 FC insulation multimeter
- Fluke i400 current clamp
- Soft case
Specifications
| Series | 15x7 Series |
