Fluke 1587KIT/62MAX+ FC Advanced Electrical Tester Kit

Overview

The Fluke 1587KIT/62MAX+ FC Advanced Electrical Tester Kit is a comprehensive diagnostic solution that combines three complementary instruments for troubleshooting and preventative maintenance. This coordinated system addresses the full range of electrical testing needs—insulation, temperature monitoring, and current measurement—without requiring multiple separate tools.

Key Features

• Fluke 1587 FC Insulation Multimeter: Insulation testing (0.01 MΩ to 2 GΩ), Pi/DAR ratio tests with TrendIt graphs, Fluke Connect cloud storage, VFD filter for motor drive measurements, CAT III 1000V/CAT IV 600V safety rating
• Fluke 62Max+ IR Thermometer: Dual rotating lasers, temperature range -30°C to 650°C, 12:1 optical resolution, min/max/average temperature display, hi/lo alarms, IP54 rated
• Fluke i400 AC Current Clamp: Measures 1A to 400A AC, 1 mA/A output, maximum conductor 32 mm diameter, CAT III 1000V/CAT IV 600V safety rating, 5 Hz to 20 kHz frequency range

Applications

• Electrical equipment diagnostics and troubleshooting
• Motor and generator maintenance programs
• Cable and switchgear testing
• Thermal imaging and hot spot detection
• Non-invasive current monitoring and circuit analysis
• Preventative maintenance on industrial electrical systems

Included Accessories

• Fluke 1587 FC insulation multimeter with remote probe, test leads, alligator clips, K-type thermocouple, and hard case
• Fluke 62Max+ IR thermometer with 2 AA batteries
• Fluke i400 AC current clamp
