Vitrek V77 Hipot and Ground Bond Tester
Request a quote
Vitrek V77 hipot tester with 2500 VAC/2750 VDC output, 8-channel switching, insulation resistance to 450GΩ, and ground bond testing capability with color touch LCD.
Product details
| Model | V77 |
| Manufacturer | Vitrek |
| Category | Hipot Testers |
| Availability | Made to order |
Description
Overview
The Vitrek V77 is an 8-channel hipot and ground bond tester from the V7X Series, combining electrical safety testing with ground continuity verification. It features color touch LCD and high-speed DSP technology for efficient production line testing.
Made in the USA to meet UL, CSA, TUV, and IEC hipot requirements, the V77 delivers 2500 VAC and 2750 VDC hipot output with insulation resistance measurement to 450GΩ and leakage current measurement to 100 nano-amps.
Key Features
- 2500 VAC and 2750 VDC hipot output
- 8-channel built-in switching (8 HV, 8 return, 8 continuity channels)
- Ground bond testing up to 30 amps (front panel channels)
- Insulation resistance measurement to 450GΩ
- Leakage current measurement to 100 nano-amps
- Color touch LCD interface
- Test memory stores up to 999 steps and 60 test sequences
- 150µS safety shutdown with ramped discharge
- USB, RS232, and Digital I/O interfaces
- 2-year warranty
Applications
- Production line electrical safety testing
- Multi-channel hipot and ground bond testing
- Medical device and appliance manufacturing
- Equipment certification and compliance testing
Included Accessories
- TL-209 probe
- Power cord
- Operating manual
- QTPro-7 software (45-day free trial)
- NIST traceable calibration certificate
Specifications
| AC Voltage | 2.5 kV |
| DC Voltage | 2.75 kV |
| Insulation Resistance Range | 450 G |
| Series | V7X Series |
| Function | AC, DC, IR, GB, LR, Scanner |
